Pavilion
Marquee Series.
Our most popular marquees are the pavilion series – also known as clearspan pavilions, because they have no poles or space restrictions, so your event can be hosted in a clear space with no interrupting infrastructure.
The 100% UV block out material and aluminium designed frame reinforces strength, making it ideal for all kinds of weather. Its versatility means it can sit on grass, be weighted on concrete and sit on more delicate groundings of timber and tiles. Structures can even be created to fit over pools!
Your pavilion marquee can have a clear roof, transparent or block out wall and can be draped with roof lining. Ultimately, the possibilities are endless.
The right pavilion.
Choosing
It's a good idea to know beforehand whether or not the marquee will be used for dancing, a sit-down dinner, a cocktail reception or require any bespoke spaces. When calculating what size marquee you need, remember to allow for any of the following: performance area, breakout spaces, kitchen, serveries, dance floors and exit ways.
Choose from the following pavilion marquee sizes...
Perfect for use as a covered walkway, add internal walls and you have created a row of festival or exhibition stands.
Perfect structure for medium sized catered events, including weddings, corporate gatherings, cocktails parties.
Ideal structure for small catered events, including weddings, corporate gatherings, cocktails parties.
Ideal structure for large sized catered events, including weddings, corporate gatherings, cocktails parties.
Pavilion
Specifications.
Pavilion marquees are available in various shapes and sizes for all sorts of functions, from weddings and family affairs to corporate functions and public events. The range extends from small marquees to large clear span pavilions.
​
A pavilion marquee is a comfortable and stylish option to the limitations presented by a standard venue. A pavilion marquee can be constructed to virtually any size and will allow your guests to enjoy the beautiful outdoor setting in perfect comfort.
​
There are many options for you to style your marquee. The walls and roof can be tastefully draped in silk lining or you can hire a pavilion with clear walls and roof, allowing you and your guests to be part of the surrounding setting with protection from the elements.
​
Your Event Solution have a range of 3m, 6m, 10m, 12m pavilions that can be extended by infinite 3 metre bays built to suit your event requirements.
Pavilion.
3 Metre
This size pavilion is perfect for use as a covered walkway, as it can be extended to infinite lengths of 3 metre bays, and can be used with or without walls on almost any surface. Add internal walls and you have created the perfect row of festival or exhibition stands. Available with walls of various styles including white, french arch, clear and coloured. Join other structures together and create a stunning entry into your main reception, or use as a catering bay to your main reception marquee.
​
Combine catering, lighting and furniture hire.
Price subject to site inspection and delivery charges.
Request a Quote to find out more.
​
Specifications
3m Pavilion
SPECIFICATIONS:
Ridge height - 2.95m
Bay distance - 3.00m
Roof pitch - 20°
Longest component - 3.74m
Minimum length - 6.00m
Maximum length - Unlimited in 3.00m increments
Max allowed wind speed - 80 km/h (0.30kN/m²)
Main profile size - 89/48/3mm (2-channel) or 110/48/3mm (4-channel)
Eave connection type - Internal Galvanised Steel Insert
Aluminium type - European - Hard Pressed Extruded Structural Aluminium
Connecting components - European - hot dipped, structural grade corrosive resistant galvanised steel
Roof covering type - Premium grade, high gloss white, PVC coated polyester fabric - UV resistant and flame retardant according to: DIN 4102 B1, M2; BS 5438/7837; USA NFPA701.
FEATURES:
​
-
Clear walls and clear roofs to entertain under the stars
-
Special peaks for a truly wonderful effect
-
Choice of ceiling linings, flat or gathered
-
Unique style doors, french doors and windows for entrance foyers and hallways
-
Technically designed compatible hard timber flooring complete with or without carpet furnishing
-
Verandahs and Batwings can be added to provide outdoor shelters
-
Specific needs can be met by combining various sized structures together to suit unique floor plans
-
Our event pavilions can be erected in most weather conditions and are designed to meet local council requirements
Pavilion.
6 Metre
The ideal structure for small catered events, including weddings, corporate gatherings and cocktails parties. The 6 metre pavilion marquee is accompanied by an integrated timber floor. Ceiling and wall linings can transform the space, along with many lighting options.
​
Combine catering, lighting and furniture hire.
Price subject to site inspection and delivery charges.
Request a Quote to find out more.
​
Specifications
6m Pavilion
SPECIFICATIONS:
Ridge height - 3.50m
Bay distance - 3.00m
Roof pitch - 20°
Number of gable uprights - 1 Gable upright (per end)
Longest component - 3.74m
Minimum length - 6.00m
Maximum length - Unlimited in 3.00m increments
Max allowed wind speed - 80 km/h (0.30kN/m²)
Main profile size - 89/48/3mm (2-channel) or 110/48/3mm (4-channel)
Eave connection type - Internal Galvanised Steel Insert
Aluminium type - European - Hard Pressed Extruded Structural Aluminium
Connecting components - European - hot dipped, structural grade corrosive resistant galvanised steel
Roof covering type - Premium grade, high gloss white, PVC coated polyester fabric - UV resistant and flame retardant according to: DIN 4102 B1, M2; BS 5438/7837; USA NFPA701.
FEATURES:
​
-
Clear walls and clear roofs to entertain under the stars
-
Special peaks for a truly wonderful effect
-
Choice of ceiling linings, flat or gathered
-
Unique style doors, french doors and windows for entrance foyers and hallways
-
Technically designed compatible hard timber flooring complete with or without carpet furnishing
-
Verandahs and Batwings can be added to provide outdoor shelters
-
Specific needs can be met by combining various sized structures together to suit unique floor plans
-
Our event pavilions can be erected in most weather conditions and are designed to meet local council requirements
Pavilion.
10 Metre
10m wide clear-span structure with 3m bays. The ideal structure for medium sized catered events, including weddings, corporate gatherings and cocktails parties. This marquee is accompanied by an integrated timber floor. Ceiling and wall linings can transform the space, along with many lighting options.
Combine catering, lighting and furniture hire.
​
Price subject to site inspection and delivery charges.
Request a Quote to find out more.
Specifications
10m Pavilion
SPECIFICATIONS:
Ridge height - 4.23m
Bay distance - 3.00m
Roof pitch - 20°
Number of gable uprights - 2 Gable upright (per end)
Longest component - 5.37m
Minimum length - 6.00m
Maximum length - Unlimited in 3.00m increments
Max allowed wind speed - 80 km/h (0.30kN/m²)
Main profile size - 89/48/3mm (2-channel) or 110/48/3mm (4-channel)
Eave connection type - Internal Galvanised Steel Insert
Aluminium type - European - Hard Pressed Extruded Structural Aluminium
Connecting components - European - hot dipped, structural grade corrosive resistant galvanised steel
Roof covering type - Premium grade, high gloss white, PVC coated polyester fabric - UV resistant and flame retardant according to: DIN 4102 B1, M2; BS 5438/7837; USA NFPA701.
FEATURES:
​
-
Clear walls and clear roofs to entertain under the stars
-
Special peaks for a truly wonderful effect
-
Choice of ceiling linings, flat or gathered
-
Unique style doors, french doors and windows for entrance foyers and hallways
-
Technically designed compatible hard timber flooring complete with or without carpet furnishing
-
Verandahs and Batwings can be added to provide outdoor shelters
-
Specific needs can be met by combining various sized structures together to suit unique floor plans
-
Our event pavilions can be erected in most weather conditions and are designed to meet local council requirements
Pavilion.
12 Metre
Clear walls and clear roofs to entertain under the stars. Add unique style doors and windows for entrance foyers and hallways. Level the ground with compatible hard timber flooring, or furnish with carpet tiles. Specific needs can be met by combining various sized structures together to suit unique floor plans.
​
Combine catering, lighting and furniture hire.
​
Price subject to site inspection and delivery charges.
Request a Quote to find out more.
Specifications
12m Pavilion
SPECIFICATIONS:
Ridge height - 4.58m
Bay distance - 3.00m
Roof pitch - 20°
Number of gable uprights - 3 Gable upright (per end)
Longest component - 6.38m
Minimum length - 6.00m
Maximum length - Unlimited in 3.00m increments
Max allowed wind speed - 80 km/h (0.30kN/m²)
Main profile size - 110/48/3mm (4-channel)
Eave connection type - Internal Galvanised Steel Insert with corner brace bar
Aluminium type - European - Hard Pressed Extruded Structural Aluminium
Connecting components - European - hot dipped, structural grade corrosive resistant galvanised steel
Roof covering type - Premium grade, high gloss white, PVC coated polyester fabric - UV resistant and flame retardant according to: DIN 4102 B1, M2; BS 5438/7837; USA NFPA701.
FEATURES:
​
-
Clear walls and clear roofs to entertain under the stars
-
Special peaks for a truly wonderful effect
-
Choice of ceiling linings, flat or gathered
-
Unique style doors, french doors and windows for entrance foyers and hallways
-
Technically designed compatible hard timber flooring complete with or without carpet furnishing
-
Verandahs and Batwings can be added to provide outdoor shelters
-
Specific needs can be met by combining various sized structures together to suit unique floor plans
-
Our event pavilions can be erected in most weather conditions and are designed to meet local council requirements
